A truck mounted crane generally consists of a cargo truck chassis, cargo compartment, power take-off, crane, and support legs. The chassis of the special vehicle for crane can be selected from Dongfeng, Jiefang, Dayun, Shaanxi Automobile, Heavy Duty Truck, etc. Commonly used cranes can be divided into XCMG cranes, Sany cranes, stone coal cranes, Hongchang Tianma cranes, etc. according to manufacturers. They can be classified into straight arm and folding arm cranes according to crane types, and into 2 tons, 3.2 tons, 5 tons, 6.3 tons, 8 tons, 10 tons, 12 tons, 16 tons, and 20 tons according to tonnage.
Vehicle model | CLW5060XLJ6 | Overall dimensions | 5995×2490×3150 (mm) |
Curb weight | 4200 kg | Chassis model | ZZ1047F341CE145 |
GVW | 4498 kg | Wheel base | 3360 mm |
Fuel tank volume | 120 L | Tire specification | 7.50R16 |
Rated passenger | 4-6 persons | Number of tires | 6 + 1 spare |
Engine parameters | |||
Engine model | ISF3.8S3141 | Displacement | 2800 ml |
Engine power | 108kw | Horsepower | 148HP |
Max speed | 100km/h | Number of cylinders | 4 |
Emission standard | EURO III | Transmission | Manual |
Fuel | Diesel | Gear box | 5MT |
System | Device Name |
Video and audio system | GPS tracking. (Per need) |
32 inch X1aomi TV under the front bed (flip board on the top) | |
Power amplifier + sound system | |
Electrical system | 3KW sine wave charging inverter integrated machine |
24V/300Ah lithium battery and low voltage protector | |
Dual battery isolator, 32A leakage protector | |
Hidden warm color car interior LED lighting/reading light/top starry sky light | |
Black acrylic switch panel | |
Circuit and electrical control system 220V inverter socket, USB charging port | |
External 220V mains interface/15m mains external plug-in line | |
4 way monitoring cameras per need | |
600W solar panel on the roof | |
A TV antenna that receives TV channels. | |
Waterway system | 280L stainless steel antifreeze water purification tank |
100L stainless steel antifreeze sewage tank | |
Vehicle intake and drainage system assembly | |
Gravity water inlet | |
Circular stainless steel vegetable washing basin (including faucet) | |
15 meters external water pipe | |
Mechanical blowdown valve | |
Fuel heater (heating, hot water) | |
Diaphragm water pump (DC12V) |
