4x2 Diesel Rear-Loading Garbage Truck | Manual Transmission Compactor with Reinforced Powertrain

A truck mounted crane generally consists of a cargo truck chassis, cargo compartment, power take-off, crane, and support legs. The chassis of the special vehicle for crane can be selected from Dongfeng, Jiefang, Dayun, Shaanxi Automobile, Heavy Duty Truck, etc. Commonly used cranes can be divided into XCMG cranes, Sany cranes, stone coal cranes, Hongchang Tianma cranes, etc. according to manufacturers. They can be classified into straight arm and folding arm cranes according to crane types, and into 2 tons, 3.2 tons, 5 tons, 6.3 tons, 8 tons, 10 tons, 12 tons, 16 tons, and 20 tons according to tonnage.

Inquiry now
[VehicleTechnical Parameters]
Product Name
Compression Garbage Truck
Kerb Weight (Kg)
15600
Overall Dimensions (mm)
11900*2550*3560 15600
Box volume (m3)
20
Box thickness (mm)
Side 4 Bottom 5
Box Body Material Quality
T355 Manganese Steel
Compression Density (t/m ³）

0.6-0.8
Working ambient temperature (℃)
20~45
Sewage Tank Capacity (L)
1600
Filling cycle time (S)
≤35
Compression cycle time (S)
≤15
Uninstall cycle time (S)
60
Operating Mode
Automatic+Manual
Max Passengers Allowed

2/3
[Chassis Technical Parameters]
Brand Name
JIEFANG
Brake
Air Brake/Oil Brake
Fuel type
Diesel
Engine Power（kw）
213
Front Axle/Rear Axle (t)

5.5/Double 10
Gearbox Model
9-Speed Manual
Number of axes
3
Wheelbase (mm)
4350+1350
Number of tires
10
Tire size
11.00R20
